( Դҳҡ )
Series : WCL
Large Flow Rate Centrifugal Pump
( 1HP - 15HP )

Mitsubishi WCL
㺾ѴѺ觹ӻҳҡ Ѻٺ觹Өҡ
Һ ͧ 㹧ҹɵ ǹ
觹Ӣѹ кл Żзҹҧ
кع¹
֧ҹçҹͧûҳҡ ٧ѡ
- кͧѹ THERMAL PROTECTOR ( ¡ 1505 , 2205 , 3705 )
- 㺾Ѵ᡹ҷӴᵹ
( WCL-5505FT , WCL-7505FT , WCL-11005FT 㺾Ѵͧͧ )


DIMENSION WCL


Performance Range
- Power up to 5HP (3.7kW)
- Flow rate up to 1,100L/min
- Total Dynamic Head up to 28 m

Features
- Mitsubishi Electric induction motor totally enclose fan cooled type IP55 protection
  with insulation class F for continous operation
- Built-in thermal protector in 1/2HP to 1 1/2HP model
- Stainless steel (SUS304) impeller with laser welding for highest strength
- Cast iron pump body with stainless steel (SUS304) shaft

Application
- Suitble for rain and gravity irrigation. Pumping water from lakes, rivers,
  well and for various kind of industrial uses where high delivery rates
  are required at low to average heads.

Model


HP

KW

çѹ俿
( V )

()

ҳ
Ե/ҷ

͹
x

Ҥ
WCL-755S
1
0.75
220V
12.7 - 4
0 - 700
2 1/2 x 2 1/2
4,858 -
WCL-1105S
1.5
1.1
220V
15 - 6.3
0 - 760
2 1/2 x 2 1/2
5,887 -
WCL-1505S
2
1.5
220V
17 - 6.8
0 - 1100
3 x 3
8,479 -
WCL-1505T
2
1.5
380V
17 - 6.8
0 - 1100
3 x 3
7,984 -
WCL-2205FS
3
2.2
220V
21.2 - 8.9
0 - 1100
3 x 3
10,955 -
WCL-2205FT
3
2.2
380V
21.2 - 8.9
0 - 1100
3 x 3
10,381 -
WCL-3705FS
5
3.7
220V
28 - 18
0 - 900
2 1/2 x 2
13,857 -
WCL-3705FT
5
3.7
380V
28 - 18
0 - 900
2 1/2 x 2
13,175 -
-WCL-1105S
Ҥһ ԵٺԪ WCL
* ҤҹŤ  ռŵ 11 .. 60
   ҤҨ¹ŧҺǧ˹
-WCL-2205FS
WCL
